Product checking and accessories
INTRODUCTION
13
1
Accessory
• Fan cover fixing screws
These screws are necessary for compliance with the EU Directives. (Refer to Instruction Manual (Startup).)
• Eyebolt for hanging the inverter
How to read the SERIAL number
Capacity Screw size (mm) Quantity
FR-A820-00105(1.5K) to FR-A820-00250(3.7K)
FR-A840-00083(2.2K), FR-A840-00126(3.7K)
M3
35
1
FR-A820-00340(5.5K), FR-A820-00490(7.5K)
FR-A840-00170(5.5K), FR-A840-00250(7.5K)
M3 35 2
FR-A820-00630(11K) to FR-A820-01250(22K)
FR-A840-00310(11K) to FR-A840-00620(22K)
M4 40 2
Capacity Eyebolt Size Quantity
FR-A840-04320(160K) to FR-A840-06830(280K) M12 2
Rating plate example
The SERIAL consists of one symbol, two characters indicating the production
year and month, and six characters indicating the control number. The last digit
of the production year is indicated as the Year, and the Month is indicated by 1
to 9, X (October), Y (November), or Z (December).
Symbol Year Month Control number
SERIAL
