Mitsubishi FR-A800

Main circuit terminals
38
INSTALLATION AND WIRING
2.5.2 Terminal layout of the main circuit terminals,
wiring of power supply and the motor
FR-A820-00046(0.4K), FR-A820-00077(0.75K)
FR-A820-00105(1.5K) to FR-A820-00250(3.7K)
FR-A840-00023(0.4K) to FR-A840-00126(3.7K)
FR-A820-00340(5.5K), FR-A820-00490(7.5K)
FR-A840-00170(5.5K), FR-A840-00250(7.5K)
FR-A820-00630(11K)
FR-A840-00310(11K), FR-A840-00380(15K)
FR-A820-00770(15K) to FR-A820-01250(22K)
FR-A840-00470(18.5K), FR-A840-00620(22K)
FR-A820-01540(30K)

FR-A840-00770(30K)
R/L1
S/L2
T/L3
N/-
P/+
PR
PX
R1/L11
S1/L21
M
Jumper
Jumper
Motor
Power supply
Charge lamp
Jumper
Jumper
MotorPower supply
M
R/L1 S/L2 T/L3
N/-
P/+ PR
R1/L11 S1/L21
PX
Charge lamp
N/-
P/+
PR
PX
R1/L11 S1/L21
Jumper
Jumper
Power supply
M
Motor
Charge lamp
R/L1 S/L2 T/L3
N/-
P/+ PR
R1/L11 S1/L21
Power supply
R/L1 S/L2 T/L3
M
Motor
Charge lamp
Jumper
Jumper
PRP3
R1/L11 S1/L21
M
R/L1 S/L2 T/L3
N/-
P/+
Power supply
Charge lamp
Jumper
Motor
Jumper
M
N/-
P/+
PRP3
R/L1 S/L2 T/L3
R1/L11 S1/L21
Power supply
Jumper
Jumper
Motor
Charge lamp
