Mitsubishi FR-A800

Position control under vector control and PM sensorless vector control
232
PARAMETERS
5.5.4 Simple positioning function by parameters
Set positioning parameters such as the number of pulses (position) and acceleration/deceleration time in advance to
create a point table (point table method). Positioning operation is performed by selecting the point table.
Pr. Name
Initial
value
Setting
range
Description
419
B000
Position command source
selection
0
0
Simple position control by point tables (position
command by setting parameters).
2 Simple pulse train command by inverter pulse input.
464
B020
Digital position control sudden
stop deceleration time
0 s 0 to 360 s
Set the time period until the inverter stops when the
forward rotation (reverse rotation) command is turned
OFF with the position feed forward function.
465
B021
First target position lower 4 digits
0 0 to 9999
Set the target position of point table 1.
466
B022
First target position upper 4 digits
0 0 to 9999
467
B023
Second target position lower 4
digits
0 0 to 9999
Set the target position of point table 2.
468
B024
Second target position upper 4
digits
0 0 to 9999
469
B025
Third target position lower 4 digits
0 0 to 9999
Set the target position of point table 3.
470
B026
Third target position upper 4 digits
0 0 to 9999
471
B027
Fourth target position lower 4 digits
0 0 to 9999
Set the target position of the point table 4.
472
B028
Fourth target position upper 4
digits
0 0 to 9999
473
B029
Fifth target position lower 4 digits
0 0 to 9999
Set the target position of the point table 5.
474
B030
Fifth target position upper 4 digits
0 0 to 9999
475
B031
Sixth target position lower 4 digits
0 0 to 9999
Set the target position of the point table 6.
476
B032
Sixth target position upper 4 digits
0 0 to 9999
477
B033
Seventh target position lower 4
digits
0 0 to 9999
Set the target position of the point table 7.
478
B034
Seventh target position upper 4
digits
0 0 to 9999
479
B035
Eighth target position lower 4 digits
0 0 to 9999
Set the target position of the point table 8.
480
B036
Eighth target position upper 4
digits
0 0 to 9999
481
B037
Ninth target position lower 4 digits
0 0 to 9999
Set the target position of the point table 9.
482
B038
Ninth target position upper 4 digits
0 0 to 9999
483
B039
Tenth target position lower 4 digits
0 0 to 9999
Set the target position of the point table 10.
484
B040
Tenth target position upper 4 digits
0 0 to 9999
485
B041
Eleventh target position lower 4
digits
0 0 to 9999
Set the target position of the point table 11.
486
B042
Eleventh target position upper 4
digits
0 0 to 9999
487
B043
Twelfth target position lower 4
digits
0 0 to 9999
Set the target position of the point table 12.
488
B044
Twelfth target position upper 4
digits
0 0 to 9999
