Mitsubishi FR-A800

Position control under vector control and PM sensorless vector control
PARAMETERS
233
5
489
B045
Thirteenth target position lower 4
digits
0 0 to 9999
Set the target position of the point table 13.
490
B046
Thirteenth target position upper 4
digits
0 0 to 9999
491
B047
Fourteenth target position lower 4
digits
0 0 to 9999
Set the target position of the point table 14.
492
B048
Fourteenth target position upper 4
digits
0 0 to 9999
493
B049
Fifteenth target position lower 4
digits
0 0 to 9999
Set the target position of the point table 15.
494
B050
Fifteenth target position upper 4
digits
0 0 to 9999
1221
B101
Start command edge detection
selection
0
0
Turning OFF the forward (reverse) rotation command
will stop the motor in the setting time of Pr.464.
1
Position forward is continued even if the forward
(reverse) rotation command is turned OFF.
1222
B120
First positioning acceleration time
5 s 0.01 to 360 s
Set the characteristics of the point table 1.
1223
B121
First positioning deceleration time
5 s 0.01 to 360 s
1224
B122
First positioning dwell time
0 ms 0 to 20000 ms
1225
B123
First positioning sub-function
10
0, 1, 10, 11,
100, 101, 110,
111
1226
B124
Second positioning acceleration
time
5 s 0.01 to 360 s
Set the characteristics of the point table 2.
1227
B125
Second positioning deceleration
time
5 s 0.01 to 360 s
1228
B126
Second positioning dwell time
0 ms 0 to 20000 ms
1229
B127
Second positioning sub-function
10
0, 1, 10, 11,
100, 101, 110,
111
1230
B128
Third positioning acceleration time
5 s 0.01 to 360 s
Set the characteristics of the point table 3.
1231
B129
Third positioning deceleration time
5 s 0.01 to 360 s
1232
B130
Third positioning dwell time
0 ms 0 to 20000 ms
1233
B131
Third positioning sub-function
10
0, 1, 10, 11,
100, 101, 110,
111
1234
B132
Fourth positioning acceleration
time
5 s 0.01 to 360 s
Set the characteristics of the point table 4.
1235
B133
Fourth positioning deceleration
time
5 s 0.01 to 360 s
1236
B134
Fourth positioning dwell time
0 ms 0 to 20000 ms
1237
B135
Fourth positioning sub-function
10
0, 1, 10, 11,
100, 101, 110,
111
1238
B136
Fifth positioning acceleration time
5 s 0.01 to 360 s
Set the characteristics of the point table 5.
1239
B137
Fifth positioning deceleration time
5 s 0.01 to 360 s
1240
B138
Fifth positioning dwell time
0 ms 0 to 20000 ms
1241
B139
Fifth positioning sub-function
10
0, 1, 10, 11,
100, 101, 110,
111
Pr. Name
Initial
value
Setting
range
Description
