(C) Motor constant parameters
440
PARAMETERS
NOTE
• Regardless of the Pr.71(Pr.450) setting, offline auto tuning can be performed according to Pr.96(Pr.463) Auto tuning
setting/status. (Refer to page 442 for offlne auto tuning.)
Using two types of motors (RT signal, Pr.450)
• When using two types of motors with one inverter, set Pr.450 Second applied motor.
• The setting value "9999" (initial value) disables second applied motor.
• If Pr.450  9999, the following parameters will be enabled by turning ON the Second function selection(RT) signal.
NOTE
• The RT signal is a second function selection signal. The RT signal also enables other second functions. (Refer to page 434.)
• The RT signal is assigned to the terminal RT in the initial status. Set "3" in any of Pr.178 to Pr.189 (input terminal function
selection) to assign the RT signal to another terminal.
• Changing the terminal assignment using Pr.178 to Pr.189 (input terminal function selection) may affect the other
functions. Set parameters after confirming the function of each terminal.
Function
RT signal ON (second
motor)
RT signal OFF (first motor)
Electronic thermal O/L relay Pr.51 Pr.9
Applied motor Pr.450 Pr.71
Control method selection Pr.451 Pr.800
Motor capacity Pr.453 Pr.80
Number of motor poles Pr.454 Pr.81
Motor excitation current Pr.455 Pr.82
Rated motor voltage Pr.456 Pr.83
Rated motor frequency Pr.457 Pr.84
Motor constant (R1) Pr.458 Pr.90
Motor constant (R2) Pr.459 Pr.91
Motor constant (L1)/d-axis inductance (Ld) Pr.460 Pr.92
Motor constant (L2)/q-axis inductance (Lq) Pr.461 Pr.93
Motor constant (X) Pr.462 Pr.94
Auto tuning setting/status Pr.463 Pr.96
Frequency search gain Pr.560 P.r298
Online auto tuning selection Pr.574 Pr.95
Induced voltage constant (phi f) Pr.738 Pr.706
Motor Ld decay ratio Pr.739 Pr.711
Motor Lq decay ratio Pr.740 Pr.712
Starting resistance tuning compensation Pr.741 Pr.717
Starting magnetic pole position detection pulse width Pr.742 Pr.721
Maximum motor frequency Pr.743 Pr.702
Motor inertia (integer) Pr.744 Pr.707
Motor inertia (exponent) Pr.745 Pr.724
Motor protection current level Pr.746 Pr.725
Torque current/Rated PM motor current Pr.860 Pr.859
