Mitsubishi FR-A800

(A) Application parameters
516
PARAMETERS
• The display of the following parameters is changed according to the C42 (Pr.934)), C44 (Pr.935), Pr.1136, and Pr1138
settings.
Changing the PID display coefficient of the LCD operation panel (FR-
LU08) or the parameter unit (FR-PU07) (Pr.759)
• Use Pr.759 PID unit selection to change the unit displayed on the FR-LU08 or the FR-PU07. For the coefficient set in
C42(Pr.934) to C44(Pr.935), the displayed units can be changed to the following units.
Pr. Name
131 PID upper limit
132 PID lower limit
133 PID action set point
553 PID deviation limit
577 Output interruption cancel level
761 Pre-charge ending level
763 Pre-charge upper detection level
1143 Second PID upper limit
1144 Second PID lower limit
755 Second PID action set point
1145 Second PID deviation limit
1149 Second output interruption cancel level
766 Second pre-charge ending level
768 Second pre-charge upper detection level
Pr. Name
Pr.759
setting
Displayed
unit
Unit name
9999 % %
0 — Not displayed
1 K Kelvin
2 C Degree Celsius
3 F Degree Fahrenheit
4 PSI Pound-force per Square Inch
5 MPa Mega Pascal
6 kPa Kilo Pascal
7 Pa Pascal
8 bar Bar
9 mbr Millibar
10 GPH Gallon per Hour
11 GPM Gallon per Minute
12 GPS Gallon per Second
13 L/H Liter per Hour
14 L/M Liter per Minute
15 L/S Liter per Second
16 CFH Cubic Feet per Hour
17 CFM Cubic Feet per Minute
18 CFS Cubic Feet per Second
19 CMH Cubic Meter per Hour
20 CMM Cubic Meter per Minute
21 CMS Cubic Meter per Second
22 ftM Feet per Minute
23 ftS Feet per Second
24 m/M Meter per Minute
25 m/S Meter per Second
26 lbH Pound per Hour
27 lbM Pound per Minute
28 lbS Pound per Second
29 iWC Inch Water Column
30 iWG Inch Water Gauge
31 fWG Feet of Water Gauge
32 mWG Meter of Water Gauge
33 iHg Inches of Mercury
34 mHg Millimeters of Mercury
35 kgH Kilograms per Hour
36 kgM Kilograms per Minute
37 kgS Kilograms per Second
38 ppm Pulse per Minute
39 pps Pulse per Second
40 kW Kilo Watt
41 hp Horse Power
42 Hz Hertz
43 rpm Revolutions per Minute
Pr.759
setting
Displayed
unit
Unit name
