Mitsubishi FR-A800

(T) Multi-Function Input Terminal Parameters
410
PARAMETERS
5.12.2 Analog input terminal (terminal 1, 4) function
assignment
• Concerning terminal 1 and terminal 4 used for analog input, the frequency (speed) command, magnetic flux command,
torque command, and other similar commands are usable. The functions available are different depending on control mode
as shown in the table below. (For control mode, see page 164.)
• Terminal 1 functions under different control modes
• Terminal 4 functions by control
NOTE
• When Pr.868 = "1" (magnetic flux command) or "4" (stall prevention/torque limit), the terminal 4 function is enabled whether
the AU terminal is turned ON/OFF.
???????
Parameters referred to
Advanced magnetic flux vector control page 170
Real sensorless vector control page 164
Pr.804 Torque command source selection page 216
Pr.807 Speed limit selection page 219
Pr.810 Torque limit input method selection page 185
Pr.840 Torque bias selection page 202
The analog input terminal 1 and terminal 4 functions are set and changeable with parameters.
Pr. Name Initial value Setting range Description
868
T010
Terminal 1 function
assignment
0 0 to 6, 9999
Select the terminal 1 function (Refer to the
table below.)
858
T040
Terminal 4 function
assignment
0 0, 1, 4, 9999
Select the terminal 4 function (Refer to the
table below.)
Pr.868
setting
V/F control
Advanced magnetic
flux vector control
Real sensorless vector control, vector control, PM sensorless vector
control
Speed control Torque control Position control
0
(initial
value)
Frequency setting auxiliary Speed setting auxiliary Speed limit assistance 
1  Magnetic flux command
 Magnetic flux command  Magnetic flux command 
2 
Regenerative torque limit
(Pr.810=1)

Regenerative torque limit
(Pr.810 = 1)
3 
Torque command (Pr.804 =
0)

4
Stall prevention operation level
input
Torque limit (Pr.810 = 1)
Torque command (Pr.804 =
0)
Torque limit (Pr.810 = 1)
5 
Forward/reverse rotation
speed limit
(Pr.807 = 2)

6 
Torque bias input
(Pr.840 =1, 2, 3)


9999 
Pr.858
setting
V/F control
Advanced magnetic
flux vector control
Real sensorless vector control, vector control, PM sensorless vector
control
Speed control Torque control Position control
0
(initial
value)
Frequency command
(AU signal-ON)
Speed command
(AU signal-ON)
Speed limit
(AU signal-ON)

1  Magnetic flux command
 Magnetic flux command  Magnetic flux command 
4
Stall prevention operation level
input
Torque limit (Pr.810 = 1)  Torque limit (Pr.810 = 1)
9999 

: No function
 This function is valid under vector control.
 Invalid when Pr.868 = "1"
 Invalid when Pr.868 = "4"
