Mitsubishi FR-A800

Parameter List
Parameter list (by parameter number)
124
PARAMETERS
Monitor functions
52 M100
Operation panel main monitor
selection
0, 5 to 14, 17 to 20,
22 to 35, 38, 40 to 45,
50 to 57, 61, 62, 64,
67, 87 to 98, 100
10 359
54 M300
FM/CA terminal function selection
1 to 3, 5 to 14, 17, 18,
21, 24, 32 to 34, 50,
52, 53, 61, 62, 67, 70,
87 to 90, 92, 93, 95,
97, 98
11 369
55 M040
Frequency monitoring reference 0 to 590 Hz 0.01 Hz 60 Hz 50 Hz 369
56 M041
Current monitoring reference
0 to 500 A
 0.01 A
Rated inverter
current
369
0 to 3600 A
 0.1 A
Automatic
restart
57 A702
Restart coasting time 0, 0.1 to 30 s, 9999 0.1 s 9999
528,
534
58 A703
Restart cushion time 0 to 60 s 0.1 s 1 s 528

59 F101
Remote function selection 0 to 3, 11 to 13 1 0 295

60 G030
Energy saving control selection 0, 4, 9 1 0 602
Automatic
acceleration/
deceleration
61 F510
Reference current
0 to 500 A, 9999
 0.01 A
9999
300,
303
0 to 3600 A, 9999
 0.1 A
62 F511
Reference value at acceleration 0 to 400%, 9999 0.1% 9999 300
63 F512
Reference value at deceleration 0 to 400%, 9999 0.1% 9999 300
64 F520
Starting frequency for elevator
mode
0 to 10 Hz, 9999 0.01 Hz 9999 303

65 H300
Retry selection 0 to 5 1 0 343

66 H611
Stall prevention operation
reduction starting frequency
0 to 590 Hz 0.01 Hz 60 Hz 50 Hz 348
Retry
67 H301
Number of retries at fault
occurrence
0 to 10, 101 to 110 1 0 343
68 H302
Retry waiting time 0.1 to 600 s 0.1 s 1 s 343
69 H303
Retry count display erase 010343

70  G107
Special regenerative brake duty 0 to 100% 0.1% 0% 614

71 C100
Applied motor
0 to 6, 13 to 16, 20,
23, 24, 30, 33, 34, 40,
43, 44, 50, 53, 54, 70,
73, 74, 330, 333, 334,
8090, 8093, 8094,
9090, 9093, 9094
10
438,
442,
452

72 E600
PWM frequency selection
0 to 15

12 277
0 to 6, 25


73 T000
Analog input selection 0 to 7, 10 to 17 1 1
406,
411

74 T002
Input filter time constant 0 to 8 1 1 413

75
-
Reset selection/disconnected PU
detection/PU stop selection
0 to 3, 14 to 17

1
14
259
0 to 3, 14 to 17,
100 to 103, 114 to 117

E100
Reset selection
0, 1
0
E101
Disconnected PU detection
E102
PU stop selection 1
E107
Reset limit
0

10
0, 1


76 M510
Fault code output selection 0 to 2 1 0 402

77 E400
Parameter write selection 0 to 2 1 0 267

78 D020
Reverse rotation prevention
selection
0 to 2 1 0 323

79 D000
Operation mode selection
0 to 4, 6, 7 1 0
306,
315
Function
Pr.
Pr.
group
Name Setting range
Minimum
setting
increments
Initial value
Refer
to
page
Customer
setting
FM CA
Simple
Simple
Simple
