Outline dimension drawings

698

SPECIFICATIONS

FR-A820-00340(5.5K), 00490(7.5K), 00630(11K)

FR-A840-00170(5.5K), 00250(7.5K), 00310(11K), 00380(15K)

FR-A820-00770(15K), 00930(18.5K), 01250(22K)

FR-A840-00470(18.5K), 00620(22K)

(Unit: mm)

195

220

7.5 H1

(7.5)

H2 H

2.3

12.5

FAN

2-φ6 hole

Inverter Model H H1 H2 D D1

FR-A820-00340(5.5K), 00490(7.5K)

FR-A840-00170(5.5K), 00250(7.5K)

260 245 1.5 170 84

FR-A820-00630(11K)

FR-A840-00310(11K), 00380(15K)

300 285 3 190 101.5

250

230

(1.5)

380 (10)

400

2.3

190

93.3

FAN

2-φ10 hole
