Mitsubishi FR-A800

Outline dimension drawings
SPECIFICATIONS
699
8
FR-A820-01540(30K)
FR-A840-00770(30K)
FR-A820-01870(37K), 02330(45K), 03160(55K), 03800(75K), 04750(90K)
FR-A840-00930(37K), 01160(45K), 01800(55K), 02160(75K), 02600(90K), 03250(110K), 03610(132K)
(Unit: mm)
(Unit: mm)
10
325
270
10
550
(10)530
3.2
(15)
52015
195
4-φ20 hole for hanging
17
2-φ10 hole
W
12
W1
10 H1
(15)
H
3.2
D
18 H2
(18)
FAN
2-φ12 hole
D1
4-φd hole
 When using a motor with a capacity of 75 kW or higher, always connect a DC reactor (FR-HEL), which is available as an option.
Inverter Model W W1 H H1 H2 d D D1
FR-A820-01870(37K), 02330(45K)
FR-A840-00930(37K), 01160(45K), 01800(55K)

435 380 550 525 514 25 250 24
FR-A820-03160(55K)
 465 410 700 675 664 25 250 22
FR-A820-03800(75K)
, 04750(90K) 465 400 740 715 704 24 360 22
FR-A840-02160(75K)
, 02600(90K) 465 400 620 595 584 24 300 22
FR-A840-03250(110K),
 03610(132K) 465 400 740 715 704 25 360 22
