Mitsubishi FR-A800

Outline dimension drawings
700
SPECIFICATIONS
FR-A840-04320(160K), 04810(185K)
FR-A840-05470(220K), 06100(250K), 06830(280K)
Always connect a DC reactor (FR-HEL), which is available as an option. (Unit: mm)
Always connect a DC reactor (FR-HEL), which is available as an option. (Unit: mm)
3-φ12 hole
12
200
498
10 985
(15)
1010
3.2
380
13 984
(13)
22
FAN
4-φ16 hole
200
300
680
12
300
13 984
(13)
1010
3.2
380
13 984 (13)
FAN
22
4-φ16 hole
3-φ12 hole
