(T) Multi-Function Input Terminal Parameters
422
PARAMETERS
Relationship between the analog input terminal function and the
calibration parameter
• Calibration parameter according to the terminal 1 function
• Calibration parameter according to the terminal 4 function
Change the torque at maximum analog input. (C18 (Pr.920), C40 (Pr.933))
• To only change the torque setting (gain) of the maximum analog input voltage (current), set to C18 (Pr.920), C40 (Pr.933).
Pr.868
setting
Terminal function
Calibration parameter
Bias setting Gain setting
0
(initial
value)
Frequency (speed)
setting auxiliary
C2 (Pr.902) Terminal 2 frequency setting
bias frequency
C3 (Pr.902) Terminal 2 frequency setting
bias
C5 (Pr.904) Terminal 4 frequency setting
bias frequency
C6 (Pr.904) Terminal 4 frequency setting
bias
Pr.125 Terminal 2 frequency setting gain
frequency
C4 (Pr.903) Terminal 2 frequency setting
gain
Pr.126 Terminal 4 frequency setting gain
frequency
C7 (Pr.905) Terminal 4 frequency setting
gain
1
Magnetic flux
command
C16 (Pr.919) Terminal 1 bias command
(torque)
C17 (Pr.919) Terminal 1 bias (torque)
C18 (Pr.920) Terminal 1 gain command
(torque)
C19 (Pr.920) Terminal 1 gain (torque)
2
Regenerative driving
torque limit
C16 (Pr.919) Terminal 1 bias command
(torque)
C17 (Pr.919) Terminal 1 bias (torque)
C18 (Pr.920) Terminal 1 gain command
(torque)
C19 (Pr.920) Terminal 1 gain (torque)
3 Torque command
4
Stall prevention
operation level

/torque limit/torque
command
5
Forward/reverse
rotation speed limit
C12 (Pr.917) Terminal 1 bias frequency
(speed)
C13 (Pr.917) Terminal 1 bias (speed)
C14 (Pr.918) Terminal 1 gain frequency
(speed)
C15 (Pr.918) Terminal 1 gain (speed)
6 Torque bias input
C16 (Pr.919) Terminal 1 bias command
(torque)
C17 (Pr.919) Terminal 1 bias (torque)
C18 (Pr.920) Terminal 1 gain command
(torque)
C19 (Pr.920) Terminal 1 gain (torque)
9999 No function 
 Adjustment of the bias and gain for stall prevention operation level is done by Pr.148 Stall prevention level at 0 V input and Pr.149 Stall
prevention level at 10 V input.
Pr.858
setting
Terminal function
Calibration parameter
Bias setting Gain setting
0
(initial
value)
Frequency (speed)
command/
Speed limit
C5 (Pr.904) Terminal 4 frequency setting
bias frequency
C6 (Pr.904) Terminal 4 frequency setting
bias
Pr.126 Terminal 4 frequency setting gain
frequency
C7 (Pr.905) Terminal 4 frequency setting
gain
1
Magnetic flux
command
C38 (Pr.932) Terminal 4 bias command
(torque)
C39 (Pr.932) Terminal 4 bias (torque)
C40 (Pr.933) Terminal 4 gain command
(torque)
C41 (Pr.933) Terminal 4 gain (torque)
4
Stall prevention
operation level 
/torque limit
C38 (Pr.932) Terminal 4 bias command
(torque)
C39 (Pr.932) Terminal 4 bias (torque)
C40 (Pr.933) Terminal 4 gain command
(torque)
C41 (Pr.933) Terminal 4 gain (torque)
9999 No function 
 Adjustment of the bias and gain for stall prevention operation level is done by Pr.148 Stall prevention level at 0 V input and Pr.149 Stall
prevention level at 10 V input.
