Removal and reinstallation of the operation panel or the front covers

INSTALLATION AND WIRING

Reinstallation of the front covers (FR-A820-01870(37K) or higher, FR-

A840-00930(37K) or higher)

(a) Insert the upper hooks of the front cover (upper side) into the sockets of the inverter.

Securely install the front cover (upper side) to the inverter by fixing the hooks on the sides of the cover into place.

(b) Tighten the mounting screw(s) at the lower part of the front cover (upper side).

NOTE

• Fully make sure that the front covers are installed securely. Always tighten the mounting screws of the front covers.

(b) (c)

(a)

Fasten
