Mitsubishi FR-A800

(D) Operation command and frequency command
322
PARAMETERS
[Explanation of terms in table]
External (EXT) : Commands from external terminal are only valid.
NET : Commands via communication are only valid.
Combined : Command from both external terminal and communication is valid.
 : Command from either of external terminal and communication is invalid.
Compensation : Commands are valid only from external terminal signals when Pr.28 Multi-speed input compensation
selection ="1".
Selectable function
Pr.178 to Pr.189 setting
28 X28
Start-time tuning start external
input
NET External
37 X37 Traverse function selection NET External
42 X42 Torque bias selection 1 NET External
43 X43 Torque bias selection 2 NET External
44 X44 P/PI control switchover NET External
45 BRI2
Second brake sequence open
completion
NET External
46 TRG Trace trigger input NET External
47 TRC Trace sampling start/end NET External
48 X48 Power failure stop external External
50 SQ Sequence start External, NET External
Pr.414="1": Valid
when there is external
or network input
Pr.414="2": External
51 X51 Fault clear Combined External
60 STF Forward rotation command NET External
61 STR Reverse rotation command NET External
62 RES Inverter reset External
64 X64
PID forward/reverse action
switchover
NET External NET External
65 X65 PU/NET operation switchover External
66 X66
External/NET operation
switchover
External
67 X67 Command source switchover External
68 NP Simple position pulse train sign External
69 CLR
Simple position droop pulse
clear
External
70 X70
DC feeding operation
permission
NET External
71 X71 DC feeding cancel NET External
72 X72 PID integral value reset NET External NET External
73 X73
Second PID P control
switchover
NET External NET External
74 X74
Magnetic flux decay output
shutoff signal
NET External
76 X76 Proximity dog External
77 X77 Pre-charge end command NET External NET External
78 X78
Second pre-charge end
command
NET External NET External
79 X79
Second PID forward/reverse
action switchover
NET External NET External
80 X80
Second PID control valid
terminal
NET External NET External
87 X87 Sudden stop Combined External
92 X92 Emergency stop External
93 X93 Torque limit selection NET External
94 X94
Control signal input for main
circuit power supply MC
External
95 X95 Converter unit fault input External
96 X96
Converter unit fault (E.OHT,
E.CPU) input
External
Operation
location
selection
Pr.338 Communication operation
command source
0: NET 1: EXT
REMARKS
Pr.339 Communication speed
command source
0:
NET
1: EXT
2:
EXT
0:
NET
1:
EXT
2:
EXT
