Mitsubishi FR-A800

(A) Application parameters
502
PARAMETERS
609
A624
PID set point/deviation
input selection
2
1 Input of set point, deviation value from terminal 1
2 Input of set point, deviation value from terminal 2
3 Input of set point, deviation value from terminal 4
4
Input of set point, deviation value via CC-Link
communication
5 Input of set point, deviation value by PLC function
610
A625
PID measured value
input selection
3
1 Input of measured value from terminal 1
2 Input of measured value from terminal 2
3 Input of measured value from terminal 4
4 Input of measured value via CC-Link communication
5 Input of measured value by sequence function
1015
A607
Integral stop selection
at limited frequency
0
0
Integral stopped at limited frequency, integral cleared during
output interruption
1
Integral continued at limited frequency, integral cleared
during output interruption
10
Integral stopped at limited frequency, integral stopped
during output interruption
11
Integral continued at limited frequency, integral stopped
during output interruption
753
A650
Second PID action
selection
0
0, 10, 11, 20, 21,
50, 51, 60, 61, 70,
71, 80, 81, 90, 91,
100, 101, 1000,
1001, 1010, 1011,
2000, 2001, 2010,
2011
Refer to Pr.128.
Set the second PID control.
For how to enable the second PID
control, refer to page 512.
754
A652
Second PID control
automatic switchover
frequency
9999 0 to 600 Hz, 9999 Refer to Pr.127.
755
A651
Second PID action set
point
9999 0 to 100%, 9999 Refer to Pr.133.
756
A653
Second PID
proportional band
100
0.1 to 1000%,
9999
Refer to Pr.129.
757
A654
Second PID integral
time
1 s
0.1 to 3600 s,
9999
Refer to Pr.130.
758
A655
Second PID differential
time
9999 0.01 to 10 s, 9999 Refer to Pr.134.
1140
A664
Second PID set point/
deviation input
selection
2 1 to 5 Refer to Pr.609.
1141
A665
Second PID measured
value input selection
3 1 to 5 Refer to Pr.610.
1143
A641
Second PID upper limit
9999 0 to 100%, 9999 Refer to Pr.131.
1144
A642
Second PID lower limit
9999 0 to 100%, 9999 Refer to Pr.132.
1145
A643
Second PID deviation
limit
9999 0 to 100%, 9999
Refer to Pr.553.
(Y205 signal is
output.)
1146
A644
Second PID signal
operation selection
0 0 to 3, 10 to 13 Refer to Pr.554.
1147
A661
Second output
interruption detection
time
1 s 0 to 3600 s, 9999 Refer to Pr.575.
1148
A662
Second output
interruption detection
level
0 Hz 0 to 600 Hz Refer to Pr.576.
1149
A663
Second output
interruption cancel level
1000% 900 to 1100% Refer to Pr.577.
Pr. Name
Initial
value
Setting range Description
