Step
Command
Description
5
Raisecom(config-
gigaethernet1/1/port)#switchport vlan-
mapping both priority-tagged [ cos cos-
value ] add-outer outer-vlan - id [ cos
cos-value ] [ remove | translate vlan-
id ]
Raisecom(config-
gigaethernet1/1/port)#switchport vlan-
mapping both cvlan custom - vlan-list
[ cos cos-value ] add-outer outer-vlan -
id [ cos cos-value ] { remove |
translate vlan-id }
Raisecom(config-
gigaethernet1/1/port)#switchport vlan-
mapping both { untag | inner inner-
vlan-id } add-outer outer-vlan - id [ cos
cos-value ]
(Optional) configure
bidirectional selective QinQ,
and add outer VLAN rules.
The device supports this
configuration on the LAG or
in ISF mode.
Double-tagged VLAN mapping cannot be concurrently configured with basic QinQ or
tagged CVLAN/Priority-tagged VLAN mapping on the same interface. Before
configuring selective QinQ and specifying CoS of the outer VLAN, configure basic
QinQ.
2.4.6 Configuring network-side interface to Trunk mode
Configure the network-side interface to Trunk mode for the ISCOM2600G-HI series switch as
below.
Step
Command
Description
1
Raisecom#config
Enter global configuration mode.
2
Raisecom(config)#interface
interface-type interface-number
Enter physical layer interface
configuration mode.
3
Raisecom(config-
gigaethernet1/1/port)#switchport
mode trunk
Configure interface trunk mode,
permit double-tagged packet to pass.
2.4.7 Configuring TPID
Configure the TPID on the network side interface for the ISCOM2600G-HI series switch as
below.
Step
Command
Description
1
Raisecom#config
Enter global configuration mode.
