ISCOM2600G-HI (A) Series Configuration Guide
7 QoS
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
319
police userc
7.8.3 Example for configuring rate limiting based on interface
Networking requirements
As shown in Figure 7-11, User A, User B, and User C are respectively connected to the
ISCOM2600G-HI series switch by Switch A, Switch B, and Switch C.
User A uses voice and video services. User B uses voice, video and data services. User C uses
video and data services.
According to service requirements, make rules as below.

Provide User A with 25 Mbit/s guaranteed bandwidth, permitting burst flow of 100
Kbytes and discarding excess flow.

Provide User B with 35 Mbit/s guaranteed bandwidth, permitting burst flow of 100
Kbytes and discarding excess flow.

Provide User C with 30 Mbit/s guaranteed bandwidth, permitting burst flow of 100
Kbytes and discarding excess flow.
Figure 7-11 Rate limiting based on interface
Configuration steps
Configure rate limiting based on interface.
Raisecom#config
Raisecom(config)#interface gigaethernet 1/1/1
Raisecom(config-gigaethernet1/1/1)#rate-limit ingress cir 25000 cbs 100
Raisecom(config-gigaethernet1/1/1)#exit
Raisecom(config)#interface gigaethernet 1/1/2
Raisecom(config-gigaethernet1/1/2)#rate-limit ingress cir 35000 cbs 100
Raisecom(config-gigaethernet1/1/2)#exit
