ISCOM2600G-HI (A) Series Configuration Guide
4 Ring network protection
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
193
G.8032 provides a mode for detecting faults based on physical interface status. The
ISCOM2600G-HI series switch learns link fault quickly and switches services immediately,
so this mode is suitable for detecting the fault between neighboring devices.
Prerequisite

Connect the interface.

Configure its physical parameters to make it Up.

Create VLANs.

Add interfaces to VLANs.
4.1.3 Default configurations of G.8032
Default configurations of G.8032 are as below.
Function
Default value
Protocol VLAN
1
Protection ring mode
Revertive
Ring WTR timer
6min
Ring protocol version
2
Guard timer
500ms
Ring Hold-off timer
0ms
G.8032 fault reported to NMS
Enable
Tributary ring virtual channel mode in intersecting node
With
Ring Propagate switch in crossing node
Disable
4.1.4 Creating G.8032 ring
Configure G.8032 for the ISCOM2600G-HI series switch as below.

Only one device on the protection ring can be configured to the Ring Protection
Link (RPL) Owner and one device is configured to the RPL neighbor. Other
devices are configured to ring forwarding nodes.

The tangent ring consists of 2 independent single rings. Configurations on the
tangent ring are identical to the ones on the common single ring. The intersecting
ring consists of a main ring and a tributary ring. Configurations on the main ring
are identical to the ones on the common single ring. For detailed configurations of
the tributary ring, see section 4.1.6 (Optional) creating G.8032 tributary ring.
Step
Command
Description
1
Raisecom#config
Enter global configuration mode.
