No.
Command
Description
1
Raisecom#show ethernet cfm
Show CFM global
configurations.
2
Raisecom#show ethernet cfm domain
[ level level ]
Show configurations of MD and
service instance.
3
Raisecom#show ethernet cfm errors
[ level level ]
Show information about the
CCM errors in the database.
4
Raisecom#show ethernet cfm lck
[ level level ] [ source ]
Show Ethernet locked signals.
5
Raisecom#show ethernet cfm local-mp
[ interface interface-type
interface-number | level level ]
Show configurations of the local
MEP.
6
Raisecom#show ethernet cfm remote-
mep [ level level ] static
Show configurations of the
static RMEP.
7
Raisecom#show ethernet cfm remote-
mep [ level level [ service
service-instance [ mpid mep-
id ] ] ]
Show information about RMEP
discovery.
8
Raisecom#show ethernet cfm
suppress-alarms [ level level ]
Show configurations of CFM
alarm suppression.
9
Raisecom#show ethernet cfm
traceroute-cache
Show information about route
discovery of the Traceroute
database.
9.3.13 Example for configuring CFM
Networking requirements
As shown in Figure 9-4, the PC communicates with the server through the network composed
by Switch A, Switch B, and Switch C. You can deploy CFM features on Switch devices to
realize carrier-grade service level, namely, to realize active fault detection, acknowledgement,
and location. Switch A and Switch C are MEPs. Switch B is the MIP, detecting Ethernet fault
from GE 1/1/1 on Switch A to GE 1/1/2 on Switch C. The MD level is 3.
