ISCOM2600G-HI (A) Series Configuration Guide
2 Ethernet
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
84
Prerequisite

Connect the interface.

Configure its physical parameters to make it Up.

Create VLANs.
2.5.3 Default configurations of VLAN mapping
Default configurations of VLAN mapping are as below.
Function
Default value
VLAN mapping status
Disable
2.5.4 Configuring VLAN mapping
Configure VLAN mapping for the ISCOM2600G-HI series switch as below.
Step
Command
Description
1
Raisecom#config
Enter global configuration mode.
2
Raisecom(config)#interface
interface-type interface-number
Enter physical layer interface
configuration mode.
3
Raisecom(config-
gigaethernet1/1/port)#switchport
vlan-mapping both outer vlan-id
translate outer vlan-id
Raisecom(config-
gigaethernet1/1/port)#switchport
vlan-mapping both outer vlan-id
inner inner -vlan-id translate
outer vlan-id inner inner -vlan-id
Configure the VLAN mapping
rule based on outer and inner
VLAN Tag in both the ingress
and egress directions of the
interface.
4
Raisecom(config-
gigaethernet1/1/1)#switchport
vlan-mapping both vlan-list
translate vlan-id
Configure the bidirectional N:1
VLAN mapping rule.

Double-tagged VLAN mapping cannot be concurrently configured with basic QinQ
or tagged CVLAN/Priority-tagged VLAN mapping on the same interface.

To configure both N:1 VLAN mapping and VLAN Copy, you must configure the
VLAN Copy and then configure N:1 VLAN mapping.
2.5.5 Checking configurations
Use the following commands to check configuration results.
