ISCOM2600G-HI (A) Series Configuration Guide
8 Multicast
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
328
8.2.2 Preparing for configurations
Scenario
Basic functions of Layer 2 multicast provide common features of Layer 2 multicast, and must
be used on the ISCOM2600G-HI series switch enabled with IGMP Snooping or IGMP MVR.
Prerequisite

Disable IGMP MVR and multicast VLAN copy in the Snooping multicast VLAN.

Add related interfaces to VLANs.
8.2.3 Default configurations of Layer 2 multicast basic functions
Default configurations of Layer 2 multicast basic functions are as below.
Function
Default value
IGMP immediate leave status
Disable
Aging time of multicast entries
260s
Interface IGMP ring network forwarding status
Disable
8.2.4 Configuring basic functions of Layer 2 multicast
Configure basic functions of Layer 2 multicast for the ISCOM2600G-HI series switch as
below.
Step
Command
Description
1
Raisecom#config
Enter global configuration mode.
2
Raisecom(config)#igmp mrouter
vlan vlan-id interface-type
interface-number
(Optional) configure the multicast
router interface.
3
Raisecom(config)#igmp member-
timeout { seconds | infinite }
(Optional) configure the aging time of
IGMP members.
4
Raisecom(config)#igmp ring
interface-type interface-
number-list
(Optional) enable IGMP ring network
forwarding on the interface.
5
Raisecom(config)#igmp report-
suppression
(Optional) enable Report suppression.
6
Raisecom(config)#igmp version
{2|3}
(Optional) configure the IGMP
version.
7
Raisecom(config)#igmp snooping
mrouter vlan vlan-list
priority priority-number
(Optional) configure the CoS priority
of the IGMP route VLAN.
