Raisecom ISCOM2600G-HI (A) Series User Manual

Raisecom
ISCOM2600G-HI (A) Series Configuration Guide
8 Multicast
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
348
Step
Command
Description
4
Raisecom(config-
gigaethernet1/1/port)#igmp
filter max-groups action
{ drop | replace } [ vlan
vlan-list ]
(Optional) configure the action over
maximum number of multicast groups in
physical interface or interface+VLAN.
Raisecom(config-port-
channel1)#igmp filter max-
groups action { drop |
replace } [ vlan vlan-list ]
(Optional) configure the action over
maximum number of multicast groups in
LAG interface or interface+VLAN.
8.6.7 Checking configurations
Use the following commands to check configuration results.
No.
Command
Description
1
Raisecom#show igmp filter [ interface |
interface-type interface-number [ vlan
vlan - id ] ]
Show configurations of
IGMP filtering.
2
Raisecom#show igmp filter profile
[ profile-number ]
Show information about
the IGMP profile.
8.6.8 Example for applying IGMP filtering on interface
Networking requirements
Enable IGMP filtering on the switch. Add filtering rules on the interface to filter multicast
users.
As shown in Figure 8-10,

Create an IGMP filtering rule Profile 1, and configure the action to pass for the multicast
group ranging from 234.5.6.7 to 234.5.6.10.

Apply filtering rule on GE 1/1/1, allow the STB to join the 234.5.6.7 multicast group,
forbid it to join the 234.5.6.11 multicast group.

Apply no filtering rule on Port 3, and allow PCs to join the 234.5.6.11 multicast group.
Configure the maximum number of multicast groups on GE 1/1/1. After the STB is added to
the 234.5.6.7 multicast group, add it to the 234.5.6.8 multicast group while it quits the
234.5.6.7 multicast group.
