ISCOM2600G-HI (A) Series Configuration Guide
7 QoS
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
303
Prerequisite
Enable global QoS.
7.5.2 Default configurations of traffic classification and traffic policy
Default configurations of traffic classification and traffic policy are as below.
Function
Default value
Traffic policy status
Disable
Traffic policy statistics status
Disable
7.5.3 Creating traffic class
Create a traffic class for the ISCOM2600G-HI series switch as below.
Step
Command
Description
1
Raisecom#config
Enter global configuration mode.
2
Raisecom(config)#class-map
class-map-name [ match-all |
match-any ]
Create a traffic class and enter traffic
classification cmap configuration mode.
3
Raisecom(config-
cmap)#description string
(Optional) configure the description of
traffic class.
7.5.4 Configuring traffic classification rules
Configure traffic classification rules for the ISCOM2600G-HI series switch as below.
Step
Command
Description
1
Raisecom#config
Enter global configuration mode.
2
Raisecom(config)#class-map
class-map-name [ match-all |
match-any ]
Create a traffic class and enter traffic
classification cmap configuration mode.
3
Raisecom(config-cmap)#match
access-list{ access-list |
name }
Raisecom(config-cmap)#exit
(Optional) configure the traffic
classification based on the ACL rule.
The ACL rule must be defined firstly and
the type must be permit.
4
Raisecom(config-cmap)#match
cos cos-value
(Optional) configure the traffic class
based on CoS of packets.
5
Raisecom(config-cmap)#match
inner-vlan inner-vlan-value
(Optional) configure the traffic class
based on inner VLAN of packets.
6
Raisecom(config-cmap)#match
vlan vlan-value
(Optional) configure the traffic class
based on VLANs of packets.
