Figure 3-11 BFD MAD networking (with intermediate device)
Configuring BFD MAD
Configure BFD MAD as below:
Step 1 Create a VLAN specially for BFD MAD (if an intermediate device is used for networking,
you should also configure it with this step).
Step 2 Determine physical interfaces (at least one on each member device) used for BFD MAD, and
add them to the VLAN specially used for BFD MAD (if an intermediate device is used for
networking, you should also configure it with this step)
Step 3 Create a VLAN interface for the VLAN specially used for BFD MAD. Enable BFD MAD on
the VLAN interface. Configure the MAD IP address.
Configure BFD MAD for the ISCOM2600G-HI series switch as below.
Enter global configuration mode.
