3.8 Configuration examples
By default, the Ethernet interface, VLAN interface, and aggregation interface are in
Down status. To configure these interfaces, use the undo shutdown command to
make them Up. Take the ISCOM2624G-HI for example.
3.8.1 Example for configuring ISF in preconfiguration mode with
BFD MAD
Networking requirements
When the network grows rapidly, the central switch (Switch A) fails to meet forwarding
requirements. To double forwarding capability based on protecting the existing investment
with easy management and maintenance, you can configure ISF.
Configuration thought
To double forwarding capability of Switch A, add Switch B to the network, and then
configure ISF on them.
When an ISF splits into two ISFs due to an ISF link fault, these two ISFs will conflict with
each other. To prevent this, configure MAD. You can configure BFD MAD to monitor the ISF
status.
