Raisecom
ISCOM2600G-HI (A) Series Configuration Guide
7 QoS
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
304
Step
Command
Description
7
Raisecom(config-cmap)#match
dscp
dscp-value
(Optional) configure the traffic class
based on DSCP rule.
8
Raisecom(config)#policy-map
policy-map-name
Raisecom(config-pmap)#class-
map
class-map-name
(Optional) configure the traffic class
based on traffic policy.
The traffic policy must have been
created, and it matching type must be
consistent with the matching type of the
traffic class.
Traffic classification rules must be created for the traffic class; in other words, the
match parameter must be configured.
For the traffic class quoted by a traffic policy, do not modify the traffic classification
rule; in other words, do not modify the match parameter of the traffic class.
7.5.5 Creating rate limiting rule and shapping rule
To limit rate of packets based on traffic policy, create a token bucket, configure rate limiting
and shaping rules on the token bucket, quote these rules to the traffic class bound to the traffic
policy.
Create rate limiting rules and shaping rule for the ISCOM2600G-HI series switch as below.
Step
Command
Description
1
Raisecom#config
Enter global configuration mode.
2
Raisecom(config)#mls qos policer-
profile
policer-name
[ single |
hierarchy | aggregate ]
Create a traffic policer profile, and
enter traffic-policer configuration
mode.
3
Raisecom(traffic-policer)#cir
cir
cbs
cbs
(Optional) configure flow mode
token bucket parameters.
Flow mode token bucket is
single token bucket, only
supporting to configure red
and green packets operation.
4
Raisecom(traffic-policer)#cir
cir
cbs
cbs
ebs
ebs
(Optional) configure RFC2697
mode token bucket parameters.
5
Raisecom(traffic-policer)#cir
cir
cbs
cbs
pir
pir
pbs
pbs
(Optional) configure RFC2698
mode token bucket parameters.
6
Raisecom(traffic-policer)#cir
cir
cbs
cbs
eir
eir
ebs
ebs
[ coupling ]
(Optional) configure RFC4115
mode or MEF token bucket
parameters.
