2.2.4 Configuring VLAN attributes
Configure VLAN attributes for the ISCOM2600G-HI series switch as below.
Step
Command
Description
1
Raisecom#config
Enter global configuration mode.
2
Raisecom(config)#create
vlan vlan-list active
Create a VLAN.
The command can also be used to create
VLANs in batches.
3
Raisecom(config)#vlan
v lan-id
Enter VLAN configuration mode.
4
Raisecom(config-
vlan)#name vlan-name
(Optional) configure the VLAN name.

The VLAN created by the vlan vlan-id command is in active status.

All configurations of VLAN do not take until the VLAN is activated.
2.2.5 Configuring interface mode
Configure the interface mode for the ISCOM2600G-HI series switch as below.
Step
Command
Description
1
Raisecom#config
Enter global configuration mode.
2
Raisecom(config)#interface
interface-type interface-number
Enter physical layer interface
configuration mode.
3
Raisecom(config-
gigaethernet1/1/port)#switchport
mode { access | trunk }
Configure the interface to Access or
Trunk mode.
2.2.6 Configuring VLAN on Access interface
Configure the VLAN on the Access interface for the ISCOM2600G-HI series switch as below.
Step
Command
Description
1
Raisecom#config
Enter global configuration mode.
2
Raisecom(config)#interface
interface-type interface-number
Enter physical layer interface
configuration mode.
3
Raisecom(config-
gigaethernet1/1/port)#switchport
mode access
Raisecom(config-
gigaethernet1/1/port)#switchport
access vlan vlan-id
Configure the interface to
Access mode, and add the
Access interface to the VLAN.
