Configuring hierarchical VLAN bandwidth guarantee
Create a hierarchical VLAN bandwidth guarantee for the ISCOM2600G-HI series switch as
below.
Step
Command
Description
1
Raisecom#config
Enter global configuration
mode.
2
Raisecom(config)#bandwidth-profile
profile-id cir cir cbs cbs [ eir eir
ebs ebs ] [ color-aware ]
Create a bandwidth guarantee
profile.
3
Raisecom(config)#hierarchy-vlan
bandwidth-profile hv-profile-id
Create a hierarchical VLAN
profile, and enter Hvlan
configuration mode.
4
Raisecom(config-hvlan)#bandwidth
vlanlist vlan-list profile-id
Raisecom(config-hvlan)#exit
Configure the hierarchical
VLAN profile.
5
Raisecom(config)#interface interface-
type interface-number
Raisecom(config-
gigaethernet1/1/*)#bandwidth { ingress
| egress } bwp-profile-id hierarchy-
vlan hv-profile-id
Apply the hierarchical
VLAN profile on the ingress
or egress interface.
If a hierarchical bandwidth guarantee profile is applied, it cannot be deleted or
modified.
7.7.6 Checking configurations
Use the following commands to check configuration results.
No.
Command
Description
1
Raisecom#show bandwidth-
profile [ bwp-profile-
id ]
Show information about the bandwidth
guarantee profile.
2
Raisecom#show bandwidth
interface interface-type
interface-number
Show information about the bandwidth
guarantee profile on the interface.
3
Raisecom#show hierarchy-
cos-bandwidth profile
[ hc-profile-id ]
Show information about the hierarchical CoS
bandwidth guarantee profile.
4
Raisecom#show hierarchy-
vlan-bandwidth profile
[ hv - profile-id ]
Show information about the hierarchical
VLAN bandwidth guarantee profile.
