Step
Command
Description
1
Raisecom#config
Enter global configuration mode.
2
Raisecom(config)#interface
interface-type interface-number
Enter physical layer interface
configuration mode.
3
Raisecom(config-
gigaethernet1/1/port)#mls qos
queue scheduler sp
Configure queue scheduling mode
as SP on the interface.
7.3.4 Configuring WRR or SP+WRR queue scheduling
Configure WRR or SP+WRR for the ISCOM2600G-HI series switch as below.
Step
Command
Description
1
Raisecom#config
Enter global configuration mode.
2
Raisecom(config)#interface
interface-type interface-number
Enter physical layer interface
configuration mode.
3
Raisecom(config-
gigaethernet1/1/port)#mls qos queue
scheduler wrr weigh1 weight2
weight3…weight8
Configure queue scheduling mode
as WRR on the interface and the
weight for each queue.
7.3.5 Configuring DRR or SP+DRR queue scheduling
Configure DRR or SP+DRR for the ISCOM2600G-HI series switch as below.
Step
Command
Description
1
Raisecom#config
Enter global configuration mode.
2
Raisecom(config)#interface
interface-type interface-
number
Enter physical layer interface configuration
mode.
3
Raisecom(config-
gigaethernet1/1/port)#mls
qos queue scheduler drr
weigh1 weight2
weight3…weight8
Configure queue scheduling mode as DRR,
and configure weight for various queues.
Conduct SP scheduling when priority of a
queue is 0.
7.3.6 Configuring queue bandwidth guarantee
Configure queue bandwidth guarantee for the ISCOM2600G-HI series switch as below.
Step
Command
Description
1
Raisecom#config
Enter global configuration mode.
