Raisecom ISCOM2600G-HI (A) Series User Manual

Raisecom
ISCOM2600G-HI (A) Series Configuration Guide
2 Ethernet
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
132
Step
Command
Description
2
Raisecom(config)#l2cp-process
tunnel destination-address
mac-address
(Optional) configure the destination
MAC address for transparently
transmitted packets.
2.12.5 Configuring L2CP profile
Configure the L2CP profile for the ISCOM2600G-HI series switch as below.
Step
Command
Description
1
Raisecom#config
Enter global configuration mode.
2
Raisecom(config)#l2cp-process
profile profile-number
Create and enter the L2CP
profile.
3
Raisecom(config-l2cp-profile)#name
string
(Optional) add profile
description.
4
Raisecom(config-l2cp-
profile)#l2cp-process protocol
{ oam | stp | dot1x | lacp | lldp
| cdp | vtp | pvst |all } action
{ tunnel | drop | peer }
(Optional) configure the mode
for processing L2CP packets.
5
Raisecom(config-l2cp-
profile)#tunnel vlan vlan-id
(Optional) configure the
specified VLAN for transparent
transmission.
6
Raisecom(config-l2cp-
profile)#tunnel interface-type
interface-number
(Optional) configure the
specified egress interface for
transparent transmission.
7
Raisecom(config-l2cp-
profile)#tunnel tunnel-type mac
(Optional) configure the type of
the tunnel for transparent
transmission.
2.12.6 Configuring L2CP profile on interface
Configure the L2CP profile on the interface for the ISCOM2600G-HI series switch as below.
Step
Command
Description
1
Raisecom#config
Enter global configuration mode.
2
Raisecom(config)#interface
interface-type interface-number
Enter physical interface
configuration mode.
3
Raisecom(config-
gigaethernet1/1/port)#l2cp
profile profile-number
Apply the L2CP profile on the
interface.
