Command
Description
Raisecom(config)#clear pppoeagent
statistic interface-type
interface-number
Clear PPPoE+ statistics. The device
supports clearing PPPoE+ statistics on the
specified interface.
10.9.8 Example for configuring PPPoE+
Networking requirements
As shown in Figure 10-12, to prevent illegal clients from accessing and managing legal users,
you can configure PPPoE+ on the Switch.

GE 1/1/1 and GE 1/1/2 are connected to Client 1 and Client 2 respectively. GE 1/1/3 is
connected to the PPPoE server.

Enable global PPPoE+, and PPPoE on GE 1/1/1 and GE 1/1/2. Configure GE 1/1/3 as
the trusted interface.

Configure the attached string of Circuit ID to raisecom, padding information about
Circuit ID on GE 1/1/1 to user01, padding information about Circuit ID on GE 1/1/2 to
the MAC address of Client 2, in ASCII format.

Enable Tag overwriting on GE 1/1/1 and GE 1/1/2.
Figure 10-12 PPPoE+ networking
Configuration steps
Step 1 Configure GE 1/1/3 as the trusted interface.
Raisecom#config
Raisecom(config)#interface gigaethernet 1/1/3
Raisecom(config-gigaethernet1/1/3)#pppoenagent trust
Raisecom(config-gigaethernet1/1/3)#exit
Step 2 Configure packet information about GE 1/1/1 and GE 1/1/2.
