Step
Command
Description
2
Raisecom(config)#interface
interface-type interface-number
Enter physical layer interface
configuration mode.
3
Raisecom(config-
gigaethernet1/1/port)#tpid tpid
Configure the TPID of the outer
VLAN Tag on the interface.
2.4.8 Checking configurations
Use the following commands to check configuration results.
No.
Command
Description
1
Raisecom#show dot1q-tunnel
Show configurations of basic QinQ.
2
Raisecom#show vlan-mapping both
interface interface-type
interface-number
Show configurations of selective
QinQ.
3
Raisecom#show vlan-mapping
interface interface-type
interface-number
Show configurations of selective QinQ
of EtherType on the interface.
2.4.9 Example for configuring basic QinQ
Networking requirements
As shown in Figure 2-7, Switch A and Switch B are connected to two branches of Department
C, which are in different locations. Department C uses VLAN 100, and needs to communicate
through VLAN 1000 of the carrier network. The carrier TPID is 9100.
Configure basic QinQ on Switch A and Switch B to enable normal communication inside a
department through the carrier's network.
