Serial peripheral interface/ inter-IC sound (SPI/I2S) RM0402

834/1163 RM0402 Rev 6

26.5 SPI interrupts

During SPI communication an interrupts can be generated by the following events:

• Transmit Tx buffer ready to be loaded

• Data received in Rx buffer

• Master mode fault

• Overrun error

• TI frame format error

Interrupts can be enabled and disabled separately.

Table 156. SPI interrupt requests

Interrupt event Event flag Enable Control bit

Transmit Tx buffer ready to be loaded TXE TXEIE

Data received in Rx buffer RXNE RXNEIE

Master Mode fault event MODF

ERRIE

Overrun error OVR

CRC error CRCERR

TI frame format error FRE
