RM0402 Rev 6 1129/1163

RM0402 Debug support (DBG)

1153

Figure 361. JTAG TAP connections

Boundary scan

TAP

NJTRST

Cortex-M4 TAP

JTMS

TMS nTRSTTMS nTRST

JTDI

JTDO

TDI TDO TDI TDO

SW-DP

STM32F4xxx

Selected

IR is 5-bit wide IR is 4-bit wide

MS19929V2
