USB on-the-go full-speed (OTG_FS) RM0402
1044/1163 RM0402 Rev 6
29.15.38 OTG device all endpoints interrupt register (OTG_DAINT)
Address offset: 0x818
Reset value: 0x0000 0000
When a significant event occurs on an endpoint, a OTG_DAINT register interrupts the
application using the device OUT endpoints interrupt bit or device IN endpoints interrupt bit
of the OTG_GINTSTS register (OEPINT or IEPINT in OTG_GINTSTS, respectively). There
is one interrupt bit per endpoint, up to a maximum of 16 bits for OUT endpoints and 16 bits
for IN endpoints. For a bidirectional endpoint, the corresponding IN and OUT interrupt bits
are used. Bits in this register are set and cleared when the application sets and clears bits in
the corresponding device endpoint-x interrupt register (OTG_DIEPINTx/OTG_DOEPINTx).
Bit 4 OTEPDM: OUT token received when endpoint disabled mask. Applies to control OUT
endpoints only.
0: Masked interrupt
1: Unmasked interrupt
Bit 3 STUPM: STUPM: SETUP phase done mask. Applies to control endpoints only.
0: Masked interrupt
1: Unmasked interrupt
Bit 2 Reserved, must be kept at reset value.
Bit 1 EPDM: Endpoint disabled interrupt mask
0: Masked interrupt
1: Unmasked interrupt
Bit 0 XFRCM: Transfer completed interrupt mask
0: Masked interrupt
1: Unmasked interrupt
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
OEPINT[15:0]
rrrrrrrrrrrrrrrr
1514131211109876543210
IEPINT[15:0]
rrrrrrrrrrrrrrrr
Bits 31:16 OEPINT[15:0]: OUT endpoint interrupt bits
One bit per OUT endpoint:
Bit 16 for OUT endpoint 0, bit 19 for OUT endpoint 3.
Bits 15:0 IEPINT[15:0]: IN endpoint interrupt bits
One bit per IN endpoint:
Bit 0 for IN endpoint 0, bit 3 for endpoint 3.
