RM0402 Rev 6 1031/1163
RM0402 USB on-the-go full-speed (OTG_FS)
1122
29.15.27 OTG host port control and status register (OTG_HPRT)
Address offset: 0x440
Reset value: 0x0000 0000
This register is available only in host mode. Currently, the OTG host supports only one port.
A single register holds USB port-related information such as USB reset, enable, suspend,
resume, connect status, and test mode for each port. It is shown in
Figure 342. The rc_w1
bits in this register can trigger an interrupt to the application through the host port interrupt
bit of the core interrupt register (HPRTINT bit in OTG_GINTSTS). On a port interrupt, the
application must read this register and clear the bit that caused the interrupt. For the rc_w1
bits, the application must write a 1 to the bit to clear the interrupt.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. PSPD[1:0]
PTCTL
[3]
rrrw
1514131211109876543210
PTCTL[2:0] PPWR PLSTS[1:0] Res. PRST PSUSP PRES
POC
CHNG
POCA
PEN
CHNG
PENA PCDET PCSTS
rw rw rw rw r r rw rs rw rc_w1 r rc_w1 rc_w1 rc_w1 r
Bits 31:19 Reserved, must be kept at reset value.
Bits 18:17 PSPD[1:0]: Port speed
Indicates the speed of the device attached to this port.
01: Full speed
10: Low speed
11: Reserved
Bits 16:13 PTCTL[3:0]: Port test control
The application writes a nonzero value to this field to put the port into a Test mode, and the
corresponding pattern is signaled on the port.
0000: Test mode disabled
0001: Test_J mode
0010: Test_K mode
0011: Test_SE0_NAK mode
0100: Test_Packet mode
0101: Test_Force_Enable
Others: Reserved
Bit 12 PPWR: Port power
The application uses this field to control power to this port, and the core clears this bit on an
overcurrent condition.
0: Power off
1: Power on
Bits 11:10 PLSTS[1:0]: Port line status
Indicates the current logic level USB data lines
Bit 10: Logic level of OTG_DP
Bit 11: Logic level of OTG_DM
Bit 9 Reserved, must be kept at reset value.
