USB on-the-go full-speed (OTG_FS) RM0402
994/1163 RM0402 Rev 6
Device-mode CSR map
These registers must be programmed every time the core changes to device mode.
OTG_HPRT 0x440 Section 29.15.27: OTG host port control and status register (OTG_HPRT)
OTG_HCCHARx
0x500
0x520
...
0x660
Section 29.15.28: OTG host channel x characteristics register
(OTG_HCCHARx)
OTG_HCINTx
0x508
0x528
....
0x668
Section 29.15.29: OTG host channel x interrupt register (OTG_HCINTx)
OTG_HCINTMSKx
0x50C
0x52C
....
0x66C
Section 29.15.30: OTG host channel x interrupt mask register
(OTG_HCINTMSKx)
OTG_HCTSIZx
0x510
0x530
....
0x670
Section 29.15.31: OTG host channel x transfer size register
(OTG_HCTSIZx)
Table 202. Host-mode control and status registers (CSRs) (continued)
Acronym
Offset
address
Register name
Table 203. Device-mode control and status registers
Acronym
Offset
address
Register name
OTG_DCFG 0x800 Section 29.15.33: OTG device configuration register (OTG_DCFG)
OTG_DCTL 0x804 Section 29.15.34: OTG device control register (OTG_DCTL)
OTG_DSTS 0x808 Section 29.15.35: OTG device status register (OTG_DSTS)
OTG_DIEPMSK 0x810
Section 29.15.36: OTG device IN endpoint common interrupt mask
register (OTG_DIEPMSK)
OTG_DOEPMSK 0x814
Section 29.15.37: OTG device OUT endpoint common interrupt mask
register (OTG_DOEPMSK)
OTG_DAINT 0x818
Section 29.15.38: OTG device all endpoints interrupt register
(OTG_DAINT)
OTG_DAINTMSK 0x81C
Section 29.15.39: OTG all endpoints interrupt mask register
(OTG_DAINTMSK)
OTG_DVBUSDIS 0x828
Section 29.15.40: OTG device V
BUS
discharge time register
(OTG_DVBUSDIS)
OTG_DVBUSPULSE 0x82C
Section 29.15.41: OTG device V
BUS
pulsing time register
(OTG_DVBUSPULSE)
