Flexible static memory controller (FSMC) RM0402

274/1163 RM0402 Rev 6

Figure 48. Wait configuration waveforms

addr[15:0] data data

addr[25:16]

Memory transaction = burst of 4 half words

HCLK

CLK

A[25:16]

NADV

NWAIT

(WAITCFG = 1)

A/D[15:0]

inserted wait state

data

NWAIT

(WAITCFG = 0)

ai15798c
