RM0402 General-purpose timers (TIM2 to TIM5)

544

Figure 143. Counter timing diagram, Update event with ARPE=1 (counter underflow)

Figure 144. Counter timing diagram, Update event with ARPE=1 (counter overflow)

MS37360V1

FD 36

CK_INT

Timerclock = CK_CNT

Counter register

Update event (UEV)

Counter underflow

Update interrupt flag (UIF)

00 02 03 04 05 06 0701

CNT_EN

Auto-reload preload register

Write a new value in TIMx_ARR

06 05 04 03 02 01

FD 36

Auto-reload active register

MS37361V1

FD 36

CK_INT

Timer clock = CK_CNT

Counter register

Update event (UEV)

Counter overflow

Update interrupt flag (UIF)

36 34 33 32 31 30 2FF8 F9 FA FB FCF7 35

CNT_EN

Auto-reload preload register

Write a new value in TIMx_ARR

Auto-reload active register

FD 36
