RM0402 General-purpose timers (TIM2 to TIM5)

544

Figure 131. Counter timing diagram, internal clock divided by N

Figure 132. Counter timing diagram, Update event when ARPE=0 (TIMx_ARR not

preloaded)

MSv37302V1

CK_INT

Timerclock = CK_CNT

Counter register

Update event (UEV)

Counter overflow

Update interrupt flag (UIF)

001F 20

FF 36

MSv37303V1

CK_INT

Timerclock = CK_CNT

Counter register

Update event (UEV)

Counter overflow

Update interrupt flag (UIF)

00 02 03 04 05 06 0732 33 34 35 3631 01

CNT_EN

Auto-reload register

Write a new value in TIMx_ARR
