RM0402 Rev 6 267/1163
RM0402 Flexible static memory controller (FSMC)
287
The differences with mode 1 are the toggling of NOE that goes on toggling after NADV
changes and the independent read and write timings.
Table 61. FSMC_BCRx bitfields (mode D)
Bit number Bit name Value to set
31:22 Reserved 0x000
21 WFDIS As needed
20 CCLKEN As needed
19 CBURSTRW 0x0 (no effect in Asynchronous mode)
18:16 CPSIZE 0x0 (no effect in Asynchronous mode)
15 ASYNCWAIT Set to 1 if the memory supports this feature. Otherwise keep at 0.
14 EXTMOD 0x1
13 WAITEN 0x0 (no effect in Asynchronous mode)
12 WREN As needed
11 WAITCFG Don’t care
10 Reserved 0x0
9 WAITPOL Meaningful only if bit 15 is 1
8 BURSTEN 0x0
7 Reserved 0x1
6 FACCEN Set according to memory support
5:4 MWID As needed
3:2 MTYP As needed
1 MUXEN 0x0
0 MBKEN 0x1
Table 62. FSMC_BTRx bitfields (mode D)
Bit number Bit name Value to set
31:30 Reserved 0x0
29:28 ACCMOD 0x3
27:24 DATLAT Don’t care
23:20 CLKDIV Don’t care
19:16 BUSTURN Time between NEx high to NEx low (BUSTURN HCLK).
15:8 DATAST
Duration of the second access phase (DATAST HCLK cycles) for read
accesses.
7:4 ADDHLD
Duration of the middle phase of the read access (ADDHLD HCLK
cycles)
3:0 ADDSET
Duration of the first access phase (ADDSET HCLK cycles) for read
accesses. Minimum value for ADDSET is 1.
