General-purpose timers (TIM2 to TIM5) RM0402

494/1163 RM0402 Rev 6

Figure 140. Counter timing diagram, internal clock divided by 2

Figure 141. Counter timing diagram, internal clock divided by 4, TIMx_ARR=0x36

1. Center-aligned mode 2 or 3 is used with an UIF on overflow.

Figure 142. Counter timing diagram, internal clock divided by N

MS37343V1

CK_INT

Timerclock = CK_CNT

Counter register

Update event (UEV)

Update interrupt flag (UIF)

CNT_EN

Counter underflow

0003 0002 0001 0000 0001 0002 0003

MS37344V1

0034 0035

CK_INT

Timerclock = CK_CNT

Counter register

Update event (UEV)

Counter overflow (cnt_ovf)

Update interrupt flag (UIF)

CNT_EN

0036 0035

MS37345V1

CK_INT

Timerclock = CK_CNT

Counter register

Update event (UEV)

Update interrupt flag (UIF)

Counter underflow

001F20 01
