RM0402 Rev 6 1025/1163
RM0402 USB on-the-go full-speed (OTG_FS)
1122
29.15.18 OTG host periodic transmit FIFO size register
(OTG_HPTXFSIZ)
Address offset: 0x100
Reset value: 0x0200 0400
29.15.19 OTG device IN endpoint transmit FIFO x size register
(OTG_DIEPTXFx)
Address offset: 0x104 + 0x04 * (x - 1), (x = 1 to 5)
Reset value: Block 1: 0x0200 0400
Reset value: Block 2: 0x0200 0600
Reset value: Block 3: 0x0200 0800
Reset value: Block 4: 0x0200 0A00
Reset value: Block 5: 0x0200 0C00
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
PTXFSIZ[15:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
1514131211109876543210
PTXSA[15:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:16 PTXFSIZ[15:0]: Host periodic Tx FIFO depth
This value is in terms of 32-bit words.
Minimum value is 16
Bits 15:0 PTXSA[15:0]: Host periodic Tx FIFO start address
This field configures the memory start address for periodic transmit FIFO RAM.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
INEPTXFD[15:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
1514131211109876543210
INEPTXSA[15:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:16 INEPTXFD[15:0]: IN endpoint Tx FIFO depth
This value is in terms of 32-bit words.
Minimum value is 16
Bits 15:0 INEPTXSA[15:0]: IN endpoint FIFOx transmit RAM start address
This field contains the memory start address for IN endpoint transmit FIFOx. The address
must be aligned with a 32-bit memory location.
