Direct memory access controller (DMA) RM0402
218/1163 RM0402 Rev 6
9.5.2 DMA high interrupt status register (DMA_HISR)
Address offset: 0x004
Reset value: 0x0000 0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. TCIF7 HTIF7 TEIF7 DMEIF7 Res. FEIF7 TCIF6 HTIF6 TEIF6 DMEIF6 Res. FEIF6
rr r r r r r r r r
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Res. Res. Res. Res. TCIF5 HTIF5 TEIF5 DMEIF5 Res. FEIF5 TCIF4 HTIF4 TEIF4 DMEIF4 Res. FEIF4
rr r r r r r r r r
Bits 31:28, 15:12 Reserved, must be kept at reset value.
Bits 27, 21, 11, 5 TCIFx: stream x transfer complete interrupt flag (x = 7 to 4)
This bit is set by hardware. It is cleared by software writing 1 to the corresponding bit in the
DMA_HIFCR register.
0: no transfer complete event on stream x
1: a transfer complete event occurred on stream x
Bits 26, 20, 10, 4 HTIFx: stream x half transfer interrupt flag (x = 7 to 4)
This bit is set by hardware. It is cleared by software writing 1 to the corresponding bit in the
DMA_HIFCR register.
0: no half transfer event on stream x
1: a half transfer event occurred on stream x
Bits 25, 19, 9, 3 TEIFx: stream x transfer error interrupt flag (x = 7 to 4)
This bit is set by hardware. It is cleared by software writing 1 to the corresponding bit in the
DMA_HIFCR register.
0: no transfer error on stream x
1: a transfer error occurred on stream x
Bits 24, 18, 8, 2 DMEIFx: stream x direct mode error interrupt flag (x = 7 to 4)
This bit is set by hardware. It is cleared by software writing 1 to the corresponding bit in the
DMA_HIFCR register.
0: no direct mode error on stream x
1: a direct mode error occurred on stream x
Bits 23, 17, 7, 1 Reserved, must be kept at reset value.
Bits 22, 16, 6, 0 FEIFx: stream x FIFO error interrupt flag (x = 7 to 4)
This bit is set by hardware. It is cleared by software writing 1 to the corresponding bit in the
DMA_HIFCR register.
0: no FIFO error event on stream x
1: a FIFO error event occurred on stream x
