RM0402 Rev 6 83/1163

RM0402 CRC calculation unit

Each write operation into the data register creates a combination of the previous CRC value

and the new one (CRC computation is done on the whole 32-bit data word, and not byte per

byte).

The write operation is stalled until the end of the CRC computation, thus allowing back-to-

back write accesses or consecutive write and read accesses.

The CRC calculator can be reset to 0xFFFF FFFF with the RESET control bit in the

CRC_CR register. This operation does not affect the contents of the CRC_IDR register.

4.4 CRC registers

The CRC calculation unit contains two data registers and a control register.The peripheral

The CRC registers have to be accessed by words (32 bits).

4.4.1 Data register (CRC_DR)

Address offset: 0x00

Reset value: 0xFFFF FFFF

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

DR [31:16]

rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

DR [15:0]

rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw

Bits 31:0 Data register bits

Used as an input register when writing new data into the CRC calculator.

Holds the previous CRC calculation result when it is read.
