RM0402 Rev 6 993/1163
RM0402 USB on-the-go full-speed (OTG_FS)
1122
Host-mode CSR map
These registers must be programmed every time the core changes to host mode.
OTG_GRXSTSR 0x01C
Section 29.15.8: OTG receive status debug read register (OTG_GRXSTSR)
Section 29.15.9: OTG receive status debug read [alternate]
(OTG_GRXSTSR)
OTG_GRXSTSP 0x020
Section 29.15.10: OTG status read and pop registers (OTG_GRXSTSP)
Section 29.15.11: OTG status read and pop registers [alternate]
(OTG_GRXSTSP)
OTG_GRXFSIZ 0x024 Section 29.15.12: OTG receive FIFO size register (OTG_GRXFSIZ)
OTG_HNPTXFSIZ/
OTG_DIEPTXF0
(1)
0x028
Section 29.15.13: OTG host non-periodic transmit FIFO size register
(OTG_HNPTXFSIZ)/Endpoint 0 Transmit FIFO size (OTG_DIEPTXF0)
OTG_HNPTXSTS 0x02C
Section 29.15.14: OTG non-periodic transmit FIFO/queue status register
(OTG_HNPTXSTS)
OTG_GCCFG 0x038 Section 29.15.15: OTG general core configuration register (OTG_GCCFG)
OTG_CID 0x03C Section 29.15.16: OTG core ID register (OTG_CID)
OTG_GLPMCFG 0x54 Section 29.15.17: OTG core LPM configuration register (OTG_GLPMCFG)
OTG_HPTXFSIZ 0x100
Section 29.15.18: OTG host periodic transmit FIFO size register
(OTG_HPTXFSIZ)
OTG_DIEPTXFx
0x104
0x108
...
0x114
Section 29.15.19: OTG device IN endpoint transmit FIFO x size register
(OTG_DIEPTXFx)
1. The general rule is to use OTG_HNPTXFSIZ for host mode and OTG_DIEPTXF0 for device mode.
Table 201. Core global control and status registers (CSRs) (continued)
Acronym
Address
offset
Register name
Table 202. Host-mode control and status registers (CSRs)
Acronym
Offset
address
Register name
OTG_HCFG 0x400 Section 29.15.21: OTG host configuration register (OTG_HCFG)
OTG_HFIR 0x404 Section 29.15.22: OTG host frame interval register (OTG_HFIR)
OTG_HFNUM 0x408
Section 29.15.23: OTG host frame number/frame time remaining register
(OTG_HFNUM)
OTG_HPTXSTS 0x410
Section 29.15.24: OTG_Host periodic transmit FIFO/queue status register
(OTG_HPTXSTS)
OTG_HAINT 0x414 Section 29.15.25: OTG host all channels interrupt register (OTG_HAINT)
OTG_HAINTMSK 0x418
Section 29.15.26: OTG host all channels interrupt mask register
(OTG_HAINTMSK)
