RM0402 Rev 6 1155/1163

RM0402 Device electronic signature

1156

Address offset: 0x08

Read only = 0xXXXX XXXX where X is factory-programmed

31.2 Flash size

Base address: 0x1FFF 7A22

Address offset: 0x00

Read only = 0xXXXX where X is factory-programmed

31.3 Package data register

Base address: 0x1FFF 7BF0

Address offset: 0x00

Read only = 0xXXXX where X is factory-programmed

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

U_ID[95:80]

rrrrrrrrrrrrrrrr

1514131211109876543210

U_ID[79:64]

rrrrrrrrrrrrrrrr

Bits 31:0 U_ID[95:64]: 95:64 Unique ID bits.

1514131211109876543210

F_SIZE

rrrrrrrrrrrrrrrr

Bits 15:0 F_ID[15:0]: Flash memory size

This bitfield indicates the size of the device Flash memory expressed in Kbytes.

1514131211109876543210

Res. Res. Res. Res. Res. PKG[2:0] Res. Res. Res. Res. Res. Res. Res. Res.

rrr
