ST STM32F412 User Manual

RM0402 Rev 6 995/1163
RM0402 USB on-the-go full-speed (OTG_FS)
1122
OTG_DIEPEMPMSK 0x834
Section 29.15.42: OTG device IN endpoint FIFO empty interrupt mask
register (OTG_DIEPEMPMSK)
OTG_DIEPCTL0 0x900
Section 29.15.43: OTG device control IN endpoint 0 control register
(OTG_DIEPCTL0)
OTG_DIEPCTLx
0x920
0x940
...
0x9A0
Section 29.15.44: OTG device IN endpoint x control register
(OTG_DIEPCTLx)
OTG_DIEPINTx
0x908
0x928
....
0x988
Section 29.15.45: OTG device IN endpoint x interrupt register
(OTG_DIEPINTx)
OTG_DIEPTSIZ0 0x910
Section 29.15.46: OTG device IN endpoint 0 transfer size register
(OTG_DIEPTSIZ0)
OTG_DTXFSTSx
0x918
0x938
....
0x998
Section 29.15.47: OTG device IN endpoint transmit FIFO status register
(OTG_DTXFSTSx)
OTG_DIEPTSIZx
0x930
0x950
...
0x9B0
Section 29.15.48: OTG device IN endpoint x transfer size register
(OTG_DIEPTSIZx)
OTG_DOEPCTL0 0xB00
Section 29.15.49: OTG device control OUT endpoint 0 control register
(OTG_DOEPCTL0)
OTG_DOEPINTx
0xB08
0xB28
...
0xBA8
Section 29.15.50: OTG device OUT endpoint x interrupt register
(OTG_DOEPINTx)
OTG_DOEPTSIZ0 0xB10
Section 29.15.51: OTG device OUT endpoint 0 transfer size register
(OTG_DOEPTSIZ0)
OTG_DOEPCTLx
0xB20
0xB40
...
0xBA0
Section 29.15.52: OTG device OUT endpoint x control register
(OTG_DOEPCTLx)
OTG_DOEPTSIZx
0xB30
0xB50
...
0xBB0
Section 29.15.53: OTG device OUT endpoint x transfer size register
(OTG_DOEPTSIZx)
Table 203. Device-mode control and status registers (continued)
Acronym
Offset
address
Register name
