Autopilot system 8 Vehicle guidance setup
9. Park the vehicle and exit the cab. Use the hitch pin hole in the drawbar as a guide to insert a
second flag in the ground to mark the tractor centerline for this pass. Note whether the second
pass is to the left or the right of the first pass.
10.
Measure the difference between the flags for the two passes and record the distance. Also
record whether the return pass is to the left or the right of the original pass. Record the results.
Note – The offset should be consistently to the left or right The following graphic shows an example of a
right offset. Measure the distance between the flags.
11. Repeat Steps 5 to 10 two more times for a total of three test runs. Use the following table to
record the offset distance and the left or right direction of offset for each test run.
12. Average the results of the three runs. (Total the offset distances from the three passes and
divide by three). Repeat Step 5 through Step 10 two more times, for a total of three test runs.
Test Run Offset distance Offset direction
1
2
3
Total =
Total / 3 (average offset value) =
184 FM-1000 Integrated Display User Guide Version 9.25, Revision B
