Control setup 9 Field-IQ system setup
Latency
Setting Explanation
On Latency By default, this is set to 0.0 seconds. Use this setting unless
you are experiencing a long response time from your clutch or
valve (this can happen on larger systems). In this case, increase
the On Latency value to compensate the delay, and the
system will turn on in advance.
Off Latency By default, this is set to 0.0 seconds. Use this setting unless
you are experiencing a long response time from your clutch or
valve (this can happen on larger systems). In this case, increase
the Off Latency value to compensate for the delay, and the
system will turn off after the set number of seconds.
Overlap
Setting Explanation
Start Overlap Distance of intentional swath overlap when entering a
previously applied area. The higher the number, the greater
the overlapped area.
End Overlap Distance of intentional swath overlap when exiting a previously
applied area. The higher the number, the greater the
overlapped area.
Coverage Switching Overlap Percentage of the section width for intentional swath overlap.
The higher the number, the greater the overlapped area
before the section is turned off.
Boundary Switching Overlap Percentage of the section width for intentional overlap of a
boundary. The higher the number, the greater the overlapped
area into the boundary area.
222 FM-1000 Integrated Display User Guide Version 9.25, Revision B
